2835球頭系列
表貼式頂部發光二極管
產品特點 / Feature
01
薄型封裝，高光效，高耐熱
02
工藝成熟，市場通用性高
03
常用于安防監控類產品
極限參數 / Limit parameters
| 正向電流 | 正向脈沖電流 | 反向電壓 | 工作溫度 | 存儲溫度 |
| IF | IFP | VR | Topr | Tstg |
| 150mA | 300mA | 5V | -40℃~85℃ | -40℃~85℃ |
Ta=25℃
Model No. | Color | Voltage | Luminous | Wavelength | Angle |
H2835AFXXXXXXX | IR n | 1.0-1.5V | 10-200mw/sr | 840-960nm | 30°/60° |
H2835AV2XXXXXX | R n | 1.8-2.6V | 500-18000mcd | 615-660nm | 30°/60° |
H2835AA2XXXXXX | A n | 1.8-2.6V | 500-18000mcd | 600-615nm | 30°/60° |
H2835AY2XXXXXX | Y n | 1.8-2.6V | 500-18000mcd | 584-596nm | 30°/60° |
H2835AG7XXXXXX | G n | 2.8-3.6V | 1000-30000mcd | 515-535nm | 30°/60° |
H2835AB1XXXXXX | B n | 2.8-3.6V | 500-18000mcd | 450-470nm | 30°/60° |
H2835AWXXXXXXX | W n | 2.8-3.6V | 1000-30000mcd | 2000-100000K | 30°/60° |
